Twido Functions



Twido Functions

Overview

The following list provides an overview of the Twido functions:

oFC_AsciiCharToInt

oFC_AsciiToInt

oFC_AsciiToReal

oFC_ConcatOfInt

oFC_CopyArrDint

oFC_CopyArrInt

oFC_CopyArrReal

oFC_CopyBitString

oFC_CopyPackedBitString

oFC_DegToRad

oFC_EqualArrDint

oFC_EqualArrReal

oFC_FindEqDint

oFC_FindEqReal

oFC_FindGtDint

oFC_FindGtReal

oFC_FindLtDint

oFC_FindLtReal

oFC_HiOfDint

oFC_IntToAscii

oFC_Lkup

oFC_LoOfDint

oFC_MaxArrDint

oFC_MaxArrReal

oFC_MeanArrReal

oFC_MinArrDint

oFC_MinArrReal

oFC_MoveArrDint

oFC_MoveArrInt

oFC_MoveArrReal

oFC_OccurArrDint

oFC_OccurArrReal

oFC_RadToDeg

oFC_RealToAscii

oFC_RolArrDint

oFC_RolArrReal

oFC_RorArrDint

oFC_RorArrReal

oFC_Round

oFC_SortArrDint

oFC_SortArrReal

oFC_SumArrDint

oFC_SumArrReal

FC_AsciiCharToInt

This function returns the 2 characters as an integer value.

If the string is invalid, the global variable G_xSystemBitS18 is set to TRUE.

FC_AsciiToInt

The ASCII to integer conversion function executes the conversion of an ASCII string value to its equivalent integer value.

The ASCII to integer instruction rules are as follows:

oThe ASCII value must be included between -32768 to 32767.

oThe function always reads the most significant byte first.

oAny ASCII character that is not in the interval [0...9] ([30 hex - 39 hex]) is considered to be an end character, except for a minus sign '-' (2D hex) when it is placed as the first character.

oIn case of an overflow (>32767 or <-32768), the global variable G_xSystemBitS18 (arithmetic overflow or detected error) is set to 1 and the value 32767 or -32768 is returned.

oIf the first character of the operand is an "end" character, the value 0 is returned and the global variable G_xSystemBitS18 is set to TRUE.

FC_AsciiToReal

The ASCII to REAL function executes the conversion of the ASCII string value to its equivalent REAL value.

ASCII to REAL conversion rules are as follows:

oThe function reads the most significant byte first.

oAny ASCII character that is not in the interval [0...9] ([30 hex - 39 hex]) is considered to be "end" character, except for:

odecimal point '.' (2E hex)

ominus '-' (2D hex)

oplus '+' (2B hex)

oexponent 'e' or 'E' (65 hex or 45 hex)

oThe ASCII string format can be in exponential notation (that is "-2.34567e+13") or in decimal notation (that is 9826.3457).

oIn case of an overflow (calculation result is > 3.402824E+38 or < -3.402824E+38):

oThe global variable G_xSystemBitS18 (arithmetic overflow or detected error) is set to TRUE.

oThe value +/- 1.#INF (+ or - infinite value) is returned.

oIf the calculation result is between -1.175494E-38 and 1.175494E-38, then the result is rounded to 0.0.

oIf the operand is not a number, the value 1.#QNAN is returned and the global variable G_xSystemBitS18 is set to TRUE.

FC_ConcatOfInt

This function concatenates two integers into a double integer.

FC_CopyArrDint

The function copies an array of DINT values to another given memory address.

FC_CopyArrInt

The function copies an array of INT values to another given memory address.

FC_CopyArrReal

The function copies an array of REAL values to another given memory address.

FC_CopyBitString

The function copies an array of BOOL values to another given memory address.

FC_CopyPackedBitString

The function copies a packed BitString of the length of i_bySize bits to another memory location.

FC_DegToRad

The function FC_DegToRad executes the conversion of an angle expressed in degree to radian.

Rules of use:

The angle to be converted must be between -737280.0 and +737280.0.

For values outside these ranges, the displayed result is + 1.#QNAN and the global variable G_xSystemBitS18 is set to TRUE.

FC_EqualArrDint

The function FC_EqualArrDint compares 2 defined size tables, element by element. If there is a difference, the rank of the first dissimilar element is returned in the form of an integer. If there is no difference, the value"-1" is returned.

The start addresses of the 2 arrays to be compared are provided at the 2 pointer inputs.

The number of elements to be compared must be defined at the input i_bySize.

FC_EqualArrReal

The function FC_EqualArrReal compares 2 defined size tables, element by element. If there is a difference shown, the rank of the first dissimilar element is returned in the form of an integer. If there is no difference, then the value -1 is returned.

The start addresses of the 2 arrays to be compared are provided at the 2 pointer inputs.

The number of elements to be compared must be defined at the input i_bySize.

FC_FindEqDint

The function FC_FindEqDint searches in a set of given DINT values for the position of the first array element, which is equal to a given value.

If the given value is not contained in the array, -1 is returned.

FC_FindEqReal

The function FC_FindEqReal searches in a set of given REAL values for the position of the first array element which is equal to a given value defined by the user.

If the given value is not contained in the array, -1 is returned.

FC_FindGtDint

The function FC_FindGtDint search in a set of given DINT values for the position of the first array element which is greater than a given value defined by the user.

If no element in the array is greater than the given value, -1 is returned.

FC_FindGtReal

The function FC_FindGtReal searches in a set of given REAL values for the position of the first array element which is greater than a given value defined by the user.

If no element in the array is greater than the given value, -1 is returned.

FC_FindLtDint

The function FC_FindLtDint searches in a set of given DINT values for the position of the first array element which is smaller than a given value defined by the user.

If no element in the array is greater than the given value, -1 is returned.

FC_FindLtReal

The function FC_FindLtReal searches in a set of given REAL values for the position of the first array element which is smaller than a given value defined by the user.

If no element in the array is greater than the given value, -1 is returned.

FC_HiOfDint

This function extracts most significant bits (MSB) of a double integer to an integer.

FC_IntToAscii

The integer to ASCII function executes the conversion of an integer value to its equivalent ASCII string value.

The integer to ASCII conversion rules are as follows:

oThe integer value must be included between -32768 to 32767.

oThe function always writes the most significant byte first.

oThe end character is "Carriage return" (ASCII 13).

oThe function automatically determines how many %MWs should be filled with ASCII values (from 1 to 4)

FC_Lkup

The function FC_Lkup is used to interpolate a set of X versus Y floating point data for a given X value.

The following conditions apply for the input value i_prSartAddr:

oeven number of values

ominimum of 6 values

ofirst element is x value to be found

osecond element is set by the function: interpolation result

oall following elements are interpolation supporting points by pairs of X and Y

Interpolation rules:

The LKUP function uses the linear interpolation rule, as defined in the following equation:





For X_i  ≤ X  ≤  X_i + 1, where i = 1 … (m-1)

Assuming X_i values are ranked in ascending order: X₁ ≤ X₂ ≤ ...X...≤ X_m-1 ≤ X_m

If any of 2 consecutive X_i values are equal (X_i=X_i+1=X), the equation 1 results in an invalid exception. To handle this exception, the following algorithm is used in place of equation 1:





For X_i = X_i+1 = X, where i = 1…(m-1).

Result value:

The result value shows if the interpolation was successful or not.

0: Successful interpolation

1: Interpolation error: incorrect array, Xm < Xm-1

2: Interpolation error: i_rXValue out of range, X < X1

4: Interpolation error: i_rXValue out of range, X > Xm

8: Invalid size of data array: i_prYValue is set as an odd number, or i_prYValue < 6

The result value does not contain the computed interpolation value (Y). For a given (X) value, the result of the interpolation (Y) is contained in i_prYValue.

i_rXValue is the floating point variable that contains the user-defined (X) value for which to compute the interpolated (Y) value.

The valid range for i_rXValue is:

X₁ ≤  i_rXValue  ≤ X_m

FC_LoOfDint

This function extracts least significant bits (LSB) of a double integer to an integer.

FC_MaxArrDint

In a set of given DINT values, this function searches the maximum value. The search is carried out only on the defined length of the table.

FC_MaxArrReal

In a set of given REAL values, this function searches the maximum value. The search is only carried out within the defined table length.

FC_MeanArrReal

In a set of given REAL values, this function is used to calculate the mean average in the required length of REAL values table.

FC_MinArrDint

In a set of given DINT values, this function searches the minimum value. The search is carried out only on the defined length of the table.

FC_MinArrReal

In a set of given REAL values, this function searches the minimum value. The search is carried out only on the defined length of the table.

FC_MoveArrDint

The function moves the input value in the DINT value tables for a number of elements equal to a given value.

FC_MoveArrInt

The function moves the input value in the INT values table for a number of elements equal to a given value.

FC_MoveArrReal

The function moves the input value in the REAL value tables for a number of elements equal to a given value.

FC_OccurArrDint

In a set of given DINT values, this function searches the number of elements equal to a given value.

FC_OccurArrReal

In a set of given REAL values, this function searches the number of elements equal to a given value.

FC_RadToDeg

This function FC_RadToDeg executes the conversion of an angle expressed in radian to degree.

Rules of use:

The angle to be converted must be between -4096Pi and 4096Pi.

For values outside these ranges, the displayed result is + 1.#QNAN and G_xSystemBitS18 is set to TRUE.

FC_RealToAscii

The REAL to ASCII function executes the conversion of REAL value to its equivalent ASCII string value.

The REAL to ASCII conversion rules are as follows:

oThe function always writes the most significant byte (MSB) first.

oThe representation is made using conventional exponential notation.

o"Infinite" or "Not a number" results return the string "NAN".

oThe end character is "Carriage return" (ASCII 13).

oThe conversion precision is 6 figures.

FC_RolArrDint

In a given DINT array this function shifts every element n position(s) towards the start address of the list. The first n elements are moved to the end of the list.

If the value of i_iShiftPosNumber is negative or 0, no shift is performed.

FC_RolArrReal

In a set of given REAL values, this function performs a rotate shift of n position(s) from top to bottom of the elements.

If the value of i_iShiftPosNumber is negative or 0, no shift is performed.

FC_RorArrDint

In a given DINT array this function shifts every element n position(s) towards the list’s end address. The last n elements are moved to the begin of the list.

If the value of i_iShiftPosNumber is negative or 0, no shift is performed.

FC_RorArrReal

In a set of given REAL values, this function performs a rotate shift of n position(s) from bottom to top of the elements.

If the value of i_iShiftPosNumber is negative or 0, no shift is performed.

FC_Round

The function FC_Round rounds a floating point representation that is stored in an ASCII string.

The ROUND instruction rules are as follows:

oThe operand is always rounded down.

oThe end character of the operand string is used as an end character for the result string.

oThe end character can be any ASCII character that is in the interval [0...9] ([30 hex - 39 hex]), except:

odot '.' (2E hex),

ominus '-' (2D hex),

oplus '+' (2B hex),

oExp 'e' or 'E' (65 hex or 45 hex).

oThe result and operand must not be longer than 13 bytes: Maximum size of an ASCII string is 13 bytes.

FC_SortArrDint

The function sorts the elements of a DINT values table in ascending or descending order and stores the result in the same table.

The direction parameter i_iSortDirection indicates the sort sequence:

odirection > 0, sorting in ascending order.

odirection < 0, sorting in descending order.

odirection = 0, no sorting is performed.

FC_SortArrReal

The function sorts the elements of a DINT values table in ascending or descending order and stores the result in the same table.

The direction parameter i_iSortDirection gives the order of the sort:

odirection > 0, sorting in ascending order.

odirection < 0, sorting in descending order.

odirection = 0, no sorting is performed.

FC_SumArrDint

The function FC_SumArrDint is used to perform the addition of a defined number of array elements whose address is defined at the input i_pdiStartAddr. This means that the function sums up all the elements of an object table.

When the result is not within the valid double word format range according to the table operand, the global variable G_xSystemBitS18 is set to TRUE.

FC_SumArrReal

The function FC_SumArrReal is used to perform the addition of a defined number of array elements whose address is defined at the input i_pdiStartAddr. This means that the function sums up all the elements of an object table.

When the result is not within the valid double word format range according to the table operand, the global variable G_xSystemBitS18 is set to TRUE.
