Axis Module - User Guide

The Smart Template Axis Module contains the functionality to parameterize a Schneider Electric axis module in a graphical way and use it in a PacDrive 3 Template or in other EcoStruxure Machine Expert software architectures.

Camera Module - User Guide

This document describes the configuration of a camera object, the calibration of a Cognex camera, the management of Cognex camera jobs, a vision server to receive data from a camera, and the configuration of a target generation, for example, to simulate products.

Conveyor Module - User Guide

The Smart Template Conveyor Module contains the functionality to parameterize a Schneider Electric axis module in a graphical way and use it in a PacDrive 3 Template or in other EcoStruxure Machine Expert software architectures.

Robot Cartesian Module - User Guide

The Smart Template Robot Cartesian Module contains the functionality to parametrize a Schneider Electric Cartesian robot in a graphical way and use it in a PacDrive 3 Template or in other EcoStruxure Machine Expert software architectures.

RobotCell Module - User Guide

The Smart Template RobotCell Module provides the functionalities to add a robot cell to an application and to add other Smart Template modules to this robot cell (for example, the Smart Template modules for robots, conveyors, cameras, or sensors).

Robot P-Series Module - User Guide

This document describes the functionality to parametrize a Schneider Electric P-Series robot in a graphical way and use it in a PacDrive 3 Template or in other software architectures.

NOTE: This help is only available in English.

Robot T-Series Module - User Guide

This document describes the functionality to parametrize a Schneider Electric T-Series robot in a graphical way and use it in a PacDrive 3 Template or in other software architectures.

Sensor Module - User Guide

The purpose of the Smart Template Sensor Module is to simplify the use of a position sensor within a PacDrive application, especially in Robot applications.

Smart Template - User Guide

This document provides information on the general part of the Smart Template modules.
