TM3AM6 / TM3AM6G Presentation
Overview
TM3AM6 (screw) and TM3AM6G (spring) analog expansion modules:
-
4 input channels 12 bits (Voltage, current)
-
2 output channels 12 bits (Voltage, current)
-
Removable screw or spring terminal block
Model Name
TM3AM6 / TM3AM6G expansion modules may present a model name, respectively TM3AM6–B / TM3AM6G–B.
Main Characteristics
|
Characteristic |
Value |
||||
|---|---|---|---|---|---|
|
Number of channels |
4 inputs |
2 outputs |
|||
|
Rated power supply |
24 Vdc |
||||
|
Signal type |
Voltage |
Current |
Voltage |
Current |
|
|
Input range |
0...10 Vdc –10...+10 Vdc |
0...20 mA 4...20 mA |
0...10 Vdc –10...+10 Vdc |
0...20 mA 4...20 mA |
|
|
Resolution |
12 bits, or 11 bits + sign |
||||
|
Connection type |
TM3AM6 |
Removable screw terminal block |
|||
|
TM3AM6G |
Removable spring terminal block |
||||
|
Cable type and length |
Type |
Twisted pair shielded |
|||
|
Length |
Maximum 30 m (98 ft) |
||||
|
Weight |
TM3AM6 |
110 g (3.88 oz) |
|||
|
TM3AM6G |
100 g (3.52 oz) |
||||
